Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| Clamping Force (lbs) | 4400 |
|---|---|
| A (in.) | 27.56 |
| A (mm) | 700 |
| B (in.) | 2.83 |
| B (mm) | 72 |
| D (in.) | 4 |
| E (in.) | 3.23 |
| G (in.) | 5/8 |
| H (in.) | 4.41 |
| I (in.) | 1.56 |
| J (in.) | 2.83 |
| P (in.) | 20 |
| Q (mm) | 2 |
| Q (in.) | 0.08 |
| R (in.) | 5/8 |
| Weight (lbs) | 66.2 |
Description
Features
- One way clamping
- High-Capacity
- High-Flexibility
- Easy to install
- 100% Tool Steel
- Dual Mounting system- Mount through bottom holes or toe clamp
- Heat treated HRC 55° & ground
