Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| Clamping Force (lbs) | 6600 |
|---|---|
| A (in.) | 5.83 |
| A (mm) | 148 |
| B (in.) | 3.94 |
| B (mm) | 100 |
| C (in.) | 2.83 |
| C (mm) | 72 |
| D (in.) | 5/8" |
| Weight (lbs) | 12.8 |
Description
Features
- Modular Clamping
- 100% Tool Steel
- Heat treated HRC 55° & ground
- Dual Mounting system: Mount through bottom holes or toe clamp
