Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
Clamping Force (lbs) | 2200 |
---|---|
A (in.) | 11.81 |
A (mm) | 300 |
B (in.) | 1.97 |
B (mm) | 50 |
D (in.) | 4 |
E (in.) | 2.39 |
G (in.) | 1/2 |
H (in.) | 2.95 |
I (in.) | 0.98 |
J (in.) | 1.97 |
P (in.) | 4 |
Q (mm) | 1.5 |
R (in.) | 1/2 |
Weight (lbs) | 14.3 |
Clamping Width - 1 pc. (in.) | 7.992 |
Clamping Width - 2 pcs. (in.) | 2.795 |
Clamping Width - 3 pcs. (in.) | 1.063 |
Description
Features
- One way clamping
- High-Capacity
- High-Flexibility
- Easy to install
- 100% Tool Steel
- Dual Mounting system- Mount through bottom holes or toe clamp
- Heat treated HRC 55° & ground
