Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| A (in.) | 19.69 |
|---|---|
| A (mm) | 500 |
| B (in.) | 9.84 |
| C (in.) | 2.95 |
| D (mm) | 400 |
| D1 (in.) | 16 |
| E (in.) | 2.05 |
| F (in.) | 3.94 |
| G/I (in.) | 5/8" |
| H (in.) | 25.98 |
| N (in.) | 4.02 |
| P (in.) | 15.75 |
| Mounting Holes | 8 |
| Weight (lbs) | 407.9 |
Description
Features
- Modular Clamping
- 100% Tool Steel
- Heat treated HRC 55° & ground
- Dual Mounting system: Mount through bottom holes or toe clamp
