Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| A (in.) | 7.36 |
|---|---|
| B (in.) | 3.35 |
| C (in.) | 3.15 |
| D (in.) | 3.62 |
| E (in.) | 2.76 |
| F (in.) | 1.97 |
| G (in.) | 0.94 |
| H (in.) | 0.35 |
| J (in.) | 1.18 |
| K (in.) | 0.67 |
| L (in.) | 0.92 |
| M (in.) | 2.36 |
| N (mm) | 14 |
| Type | Ground |
| Clamping Force (lbs) | 7500 |
| Weight (lbs) | 12.32 |
Description
Material/Finish
- Jaw: S45C Steel HRC40
- Vise Body: FCD45 (Normalized)
Application
- Ideal for holding large or irregular-shaped workpieces that cannot fit on a standard.
Features
- Clamping force in two directions, available with plain or serrated jaws.
