Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| A (in.) | 5.24 |
|---|---|
| B (in.) | 2.36 |
| C (in.) | 2.28 |
| D (in.) | 2.68 |
| E (in.) | 1.97 |
| F (in.) | 1.26 |
| G (in.) | 0.63 |
| H (in.) | 0.24 |
| J (in.) | 0.87 |
| K (in.) | 0.51 |
| L (in.) | 0.66 |
| M (in.) | 1.65 |
| N (mm) | 10 |
| Type | Ground |
| Clamping Force (lbs) | 4600 |
| Weight (lbs) | 4.62 |
Description
Material/Finish
- Jaw: S45C Steel HRC40
- Vise Body: FCD45 (Normalized)
Application
- Ideal for holding large or irregular-shaped workpieces that cannot fit on a standard.
Features
- Clamping force in two directions, available with plain or serrated jaws.
