Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| A (mm) | 800 |
|---|---|
| A (in.) | 31.5 |
| B (in.) | 9.85 |
| C (in.) | 31.69 |
| D (in.) | 2.36 |
| E (mm) | 640 |
| E1 (in.) | 25 |
| F (mm) | 135 |
| G (in.) | 29.53 |
| I (mm) | 80 |
| Mounting Holes | 6 |
| Weight (lbs) | 1136 |
Description
Material
FC300 series high strength Cast Iron – stress relievedMounting Holes
Designed to fit all INCH & MM pallets (other configurations available)Accuracy
Flat, parallel & square < .001″ over 12″Features
- Designed to accept QC Sub – Plate
- Either Plain or Tapped & Bushed
- 3 Point mounting system
- Fast & Accurate
