Specifications
Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.
| A (mm) | 500 |
|---|---|
| A (in.) | 19.69 |
| B (in.) | 5.91 |
| C (in.) | 19.88 |
| D (in.) | 2.17 |
| E (mm) | 400 |
| E1 (in.) | 16 |
| F (mm) | 75 |
| G (in.) | 17.72 |
| I (mm) | 75 |
| Mounting Holes | 6 |
| Weight (lbs) | 392 |
Description
Material
FC300 series high strength Cast Iron – stress relievedMounting Holes
Designed to fit all INCH & MM pallets (other configurations available)Accuracy
Flat, parallel & square < .001″ over 12″Features
- Designed to accept QC Sub – Plate
- Either Plain or Tapped & Bushed
- 3 Point mounting system
- Fast & Accurate
