Grey 3D render of a wide rectangular grid plate with an extensive multi-hole pattern.

BP02 Subplate (#D048)

$3,900.00

Download 2DDownload 2D (.PDF) Download 3DDownload 3D (.STP)
For more information:
Call us at 631-385-9452 or visit our contact page
💰💵 Lower your tax bill with this item!
Specifications

Please note: Some specifications below are rounded, please refer to PDF/CAD files for exact dimensions.

Engineering blueprint of a grid-patterned machine base plate with dimensions.
A (in.)

24
B (in.)

54
C (in.)

52
E (in.)

As Required
F (in.)

As Required
MTP Holes

336
Weight (lbs)

492

Description

Material

FC300 series high strength cast iron – stress relieved

Accuracy

Flat, parallel & square < .001″ over 12″

Hole Grid

  • 12mm MTP holes on 2" grid
  • Hardened thread inserts & bushings in every hole.
  • Surface ground top & bottom
  • Grid location is marked on face
We can custom build any SUB PLATE to fit your special needs. 1/2″ & MM holes available.
